Power and signal shipboard cable for fixed installation at all ship’s levels (including outer deck) acc. to IEC 60092-352 standard. Specially suitable for passenger ships because ofimproved characteristics under fire. Also applied at open sea platforms. Copper braid acts as reinforcement and screen against external electromagnetic impacts.

advantages:
- halogen-free, no release of toxic and corrosive gases under fire
- reduced smoke manifestation under fire
- no flame propagation in vertical cable bundle, flame retardant
- resistant to oils and greases
- improved mechanical characteristics, resistant to scraping and vibrations
- smaller cable diameter and weight

Construction

Temperature range:
during installation:	-20 °C up to +70 °C
fixed installed:	-30 °C up to +80 °C
max operating temperature:	90 °C (or 85 °C)
Nominal voltage:	Uο/U = 0,6/1 kV
Test voltage:	3,5 kV
Minimal inner bending radius:
round conductor:	6D
sector conductor:	8D
Flame retardant:	IEC 60332-1
Flame resistant:	IEC 60332-3 kat. A
Halogen-free:	IEC 60754-1
Non-corrosive combustion gases:	IEC 60754-2
Low smoke density:	IEC 61034-2

Conductor:		bare or tinned copper conductor, multi wire stranded, class 2 acc. to IEC 60228 / HD 383 / DIN VDE 0295, round or sector
Insulation:		cross-linked polyethylene - XLPE, acc. to IEC 60092-351 (more recent mark for cross-linked polyethylene: PE-X), concentrically stranded cores, with or without green-yellow protective conductor
Filler / inner sheath:		polyolefin based compound; or without filler, with separator of polyester tape
Armour / Screen:		: braid of tinned copper wires, min. overlap 90%
Sheath:		polyolefin, type SHF1 or SHF2 acc. to IEC 60092-359
sheath colour:		black or grey

Dimensions - number of cores x conductor cross-section	Construction	Construction of individual conductor	External diameter	Insulation thickness	Sheath thickness	Conductor resistance at 20 °C	Permitted stress	Cable weight	Packing*
		nominal	approx.	nominal	nominal	max.	max.	approx.
N x mm²		n x mm	mm	mm	mm	Ω/km	N	kg/km
1 x 1,5	RM	7 x 0.52	8	0.7	1	12.2	22.5	95	CUT
1 x 2,5	RM	7 x 0.67	8.5	0.7	1	7.560	37.5	120	CUT
1 x 4	RM	7 x 0.85	9	0.7	1.1	4.700	60	140	CUT
1 x 6	RM	7 x 15	9.5	0.7	1.1	3.110	90	160	CUT
1 x 10	RM	7 x 1.35	10.5	0.7	1.1	1.840	150	220	CUT
1 x 16	RM	7 x 1.70	12	0.7	1.2	1.160	240	300	CUT
1 x 25	RM	7 x 2.13	13.5	0.9	1.2	0.734	375	410	CUT
1 x 35	RM	7 x 2.52	15.5	0.9	1.3	0.529	525	570	CUT
1 x 50	RM	19 x 1.83	17	1	1.3	0.391	750	730	CUT
1 x 70	RM	19 x 2.17	19	1.1	1.4	0.270	1050	970	CUT
1 x 95	RM	19 x 2.52	21	1.1	1.5	0.195	1425	1250	CUT
1 x 120	RM	37 x 23	23	1.2	1.5	0.154	1800	1530	CUT
1 x 150	RM	37 x 2.27	25.5	1.4	1.6	0.126	2250	1860	CUT
1 x 185	RM	37 x 2.52	28	1.6	1.7	0.100	2775	2260	CUT
1 x 240	RM	61 x 2.24	31	1.7	1.8	0.076	3600	2830	CUT
1 x 300	RM	61 x 2.50	33.5	1.8	1.9	0.061	4500	3450	CUT

2 x 1	RM	7 x 0.43	11	0.7	1.1	18.2	30	175	CUT
2 x 1,5	RM	7 x 0.52	12	0.7	1.1	12.2	45	185	CUT
2 x 2,5	RM	7 x 0.67	13	0.7	1.2	7.560	75	235	CUT
2 x 4	RM	7 x 0.85	14	0.7	1.2	4.700	120	300	CUT
2 x 6	RM	7 x 15	16	0.7	1.3	3.110	180	405	CUT
2 x 10	RM	7 x 1.35	18	0.7	1.3	1.840	300	550	CUT
2 x 16	RM	7 x 1.70	20	0.7	1.4	1.160	480	750	CUT
2 x 25	RM	7 x 2.13	23.5	0.9	1.5	0.734	750	1040	CUT
2 x 35	RM	7 x 2.52	26	0.9	1.6	0.529	1050	1360	CUT
2 x 50	RM	19 x 1.83	29	1	1.7	0.391	1500	1790	CUT
2 x 70	RM	19 x 2.17	33	1.1	1.9	0.270	2100	2420	CUT
2 x 95	RM	19 x 2.52	38	1.1	2	0.195	2850	3410	CUT
2 x 120	RM	37 x 23	42.5	1.2	2.2	0.154	3600	4080	CUT
2 x 150	RM	37 x 2.27	47	1.4	2.3	0.126	4500	4960	CUT
2 x 185	RM	37 x 2.52	52	1.6	2.5	0.100	5550	6090	CUT
2 x 240	RM	61 x 2.24	59	1.7	2.7	0.076	72	7670	CUT
2 x 300	RM	61 x 2.50	64	1.8	2.9	0.061	90	9400	CUT

3 x 1	RM	7 x 0.43	11.5	0.7	1.1	18.2	45	180	CUT
3 x 1,5	RM	7 x 0.52	12.5	0.7	1.2	12.2	67.5	210	CUT
3 x 2,5	RM	7 x 0.67	13.5	0.7	1.2	7.560	112.5	265	CUT
3 x 4	RM	7 x 0.85	14.5	0.7	1.2	4.700	180	350	CUT
3 x 6	RM	7 x 15	16	0.7	1.3	3.110	270	455	CUT
3 x 10	RM	7 x 1.35	19	0.7	1.4	1.840	450	640	CUT
3 x 16	RM	7 x 1.70	21	0.7	1.5	1.160	720	900	CUT
3 x 25	RM	7 x 2.13	25	0.9	1.6	0.734	1125	1280	CUT
3 x 35	RM	7 x 2.52	28	0.9	1.7	0.529	1575	1690	CUT
3 x 50	SM	19 x 1.83	27	1	1.7	0.391	2250	2100	CUT
3 x 70	SM	19 x 2.17	29	1.1	1.8	0.270	3150	2800	CUT
3 x 95	SM	19 x 2.52	33	1.1	1.9	0.195	4275	3700	CUT
3 x 120	SM	37 x 23	37	1.2	2.1	0.154	5400	4600	CUT
3 x 150	SM	37 x 2.27	41	1.4	2.2	0.126	6750	5280	CUT
3 x 185	SM	37 x 2.52	46	1.6	2.4	0.100	8325	5800	CUT
3 x 240	SM	61 x 2.24	49	1.7	2.5	0.076	10800	7150	CUT
3 x 300	SM	61 x 2.50	56	1.8	2.8	0,061	13500	11100	CUT

4 x 1	RM	7 x 0.43	12	0.7	1.2	18.2	60	175	CUT
4 x 1,5	RM	7 x 0.52	13	0.7	1.2	12.2	90	240	CUT
4 x 2,5	RM	7 x 0.67	14.5	0.7	1.2	7.560	150	325	CUT
4 x 4	RM	7 x 0.85	16	0.7	1.3	4.700	240	420	CUT
4 x 6	RM	7 x 15	18	0.7	1.3	3.110	360	585	CUT
4 x 10	RM	7 x 1.35	20	0.7	1.4	1.840	600	800	CUT
4 x 16	RM	7 x 1.70	23	0.7	1.5	1.160	960	1140	CUT
4 x 25	RM	7 x 2.13	27	0.9	1.7	0.734	1500	1600	CUT
4 x 35	RM	7 x 2.52	30	0.9	1.8	0.529	2100	2160	CUT
4 x 50	SM	19 x 1.83	31.5	1	1.9	0.391	30	2750	CUT
4 x 70	SM	19 x 2.17	37	1.1	2.1	0.270	42	3800	CUT
4 x 95	SM	19 x 2.52	41	1.1	2.2	0.195	5700	5050	CUT
4 x 120	SM	37 x 23	44	1.2	2.3	0.154	72	62	CUT
4 x 150	SM	37 x 2.27	49	1.4	2.5	0.126	90	7500	CUT
4 x 185	SM	37 x 2.52	54	1.6	2.7	0.100	11100	9350	CUT
4 x 240	SM	61 x 2.24	60	1.7	2.9	0.076	14400	120	CUT
4 x 300	SM	61 x 2.50	65	1.8	3.1	0.061	180	14650	CUT

5 x 1	RM	7 x 0.43	13.5	0.7	1.2	18.2	75	250	CUT
7 x 1	RM	7 x 0.43	14	0.7	1.2	18.2	105	320	CUT
10 x 1	RM	7 x 0.43	17	0.7	1.3	18.2	150	410	CUT
12 x 1	RM	7 x 0.43	18	0.7	1.4	18.2	180	470	CUT
14 x 1	RM	7 x 0.43	18.5	0.7	1.4	18.2	210	515	CUT
16 x 1	RM	7 x 0.43	19.5	0.7	1.4	18.2	240	565	CUT
19 x 1	RM	7 x 0.43	20	0.7	1.4	18.2	285	630	CUT
24 x 1	RM	7 x 0.43	23	0.7	1.5	18.2	360	765	CUT
27 x 1	RM	7 x 0.43	24	0.7	1.6	18.2	405	795	CUT
30 x 1	RM	7 x 0.43	24.5	0.7	1.6	18.2	450	880	CUT
37 x 1	RM	7 x 0.43	26	0.7	1.6	18.2	555	1020	CUT
48 x 1	RM	7 x 0.43	29.5	0.7	1.8	18.2	720	1250	CUT
61 x 1	RM	7 x 0.43	32	0.7	1.8	18.2	915	1500	CUT

5 x 1,5	RM	7 x 0.52	14.5	0.7	1.2	12.2	112.5	315	CUT
7 x 1,5	RM	7 x 0.52	15.5	0.7	1.3	12.2	157.5	400	CUT
10 x 1,5	RM	7 x 0.52	18	0.7	1.4	12.2	225	520	CUT
12 x 1,5	RM	7 x 0.52	19	0.7	1.4	12.2	270	585	CUT
14 x 1,5	RM	7 x 0.52	20	0.7	1.4	12.2	315	630	CUT
16 x 1,5	RM	7 x 0.52	21.5	0.7	1.5	12.2	360	690	CUT
19 x 1,5	RM	7 x 0.52	22	0.7	1.5	12.2	427.5	770	CUT
24 x 1,5	RM	7 x 0.52	25	0.7	1.6	12.2	540	940	CUT
27 x 1,5	RM	7 x 0.52	26	0.7	1.6	12.2	607.5	1010	CUT
30 x 1,5	RM	7 x 0.52	27	0.7	1.7	12.2	675	1110	CUT
37 x 1,5	RM	7 x 0.52	29	0.7	1.7	12.2	832.5	1320	CUT
48 x 1,5	RM	7 x 0.52	33	0.7	1.9	12.2	1080	1580	CUT
61 x 1,5	RM	7 x 0.52	36	0.7	2	12.2	1372.5	1990	CUT

5 x 2,5	RM	7 x 0.67	16	0.7	1.3	7.560	187.5	420	CUT
7 x 2,5	RM	7 x 0.67	17	0.7	1.3	7.560	262.5	510	CUT
10 x 2,5	RM	7 x 0.67	20	0.7	1.5	7.560	375	640	CUT
12 x 2,5	RM	7 x 0.67	21	0.7	1.5	7.560	450	735	CUT
14 x 2,5	RM	7 x 0.67	22	0.7	1.5	7.560	525	795	CUT
16 x 2,5	RM	7 x 0.67	23	0.7	1.5	7.56	600	880	CUT
19 x 2,5	RM	7 x 0.67	25	0.7	1.6	7.56	712.5	930	CUT
24 x 2,5	RM	7 x 0.67	28	0.7	1.7	7.56	900	1250	CUT
27 x 2,5	RM	7 x 0.67	29	0.7	1.7	7.56	1012.5	1340	CUT
30 x 2,5	RM	7 x 0.67	30	0.7	1.8	7.56	1125	1460	CUT
37 x 2,5	RM	7 x 0.67	32	0.7	1.8	7.56	1387.5	1730	CUT
48 x 2,5	RM	7 x 0.67	36	0.7	2	7.56	1800	22	CUT
61 x 2,5	RM	7 x 0.67	40	0.7	2.1	7.56	2287.5	2760	CUT
